Agilent Technologies G7117C User Manual

Agilent InfinityLab LC Series Diode Array Detectors User Manual 208
13 LAN Configuration
Configuration Switches
Configuration Switches
The configuration switch can be accessed at the rear of the module.
Figure 58 Location of Configuration switch (example shows a G7114A/B VWD)
The module is shipped with all switches set to OFF, as shown above.
Configuration switch
NOTE
To perform any LAN configuration, SW1 and SW2 must be set to OFF.
