Agilent InfinityLab LC Series Diode Array Detectors User Manual 71
4 Preparing the Module
Installing Capillaries
Installing Capillaries
Capillaries and connections depend on which system is installed.
Table 11 Capillary connections for 1260 Infinity II systems
p/n From To
Bottle Head Assembly (G7120-60007) Solvent Bottle Infinity II Pump
Capillary ST 0.17 mm x 500 mm SI/SI (5500-1246) Pump Sampler
Capillary, ST, 0.17 mm x 900 mm SI/SX (5500-1217) Pump Vialsampler with ICC
Capillary ST 0.17 mm x 500 mm SI/SI (5500-1246) Multisampler MCT Valve/Heat Exchanger
Capillary, ST, 0.17 mm x 400 mm SL/SL (5500-1252) Vialsampler MCT Valve/Heat Exchanger
Capillary ST 0.17 mm x 105 mm SL/SL (5500-1240) Vialsampler ICC Heat Exchanger
Capillary, ST, 0.17 mm x 120 mm SL/SL, long socket
(5500-1250)
ICC Heat Exchanger Column
InfinityLab Quick Turn Capillary ST 0.17 mm x 105 mm, long
socket (5500-1193)
MCT Heat Exchanger Column
InfinityLab Quick Turn Capillary ST 0.12 mm x 280 mm, long
socket (5500-1191)
Column/MCT Valve Detector
Waste accessory kit (5062-8535) VWD Waste
Tube PTFE 0.7 mm x 5 m, 1.6 mm od (5062-2462) DAD/FLD Waste
Analytical tubing kit 0.25 mm i.d. PTFE-ESD (G5664-68712) Detector Fraction Collector
Table 12 Capillary connections for 1290 Infinity II systems
p/n From To
Bottle Head Assembly (G7120-60007) Solvent Bottle Infinity II Pump
Capillary ST 0.17 mm x 400 mm SI/SI (5500-1245) Pump Sampler
Capillary, ST, 0.17 mm x 900 mm SI/SX (5500-1217) Pump Vialsampler with ICC
Capillary ST, 0.12 mm x 500 mm SL/S (5500-1157) Multisampler MCT Valve/Heat Exchanger
Capillary ST 0.12 mmX 400 mm SL/SL (5500-1251) Vialsampler MCT Valve/Heat Exchanger
Capillary ST 0.12 mm x 105 mm SL/SL (5500-1238) Vialsampler ICC Heat Exchanger
