Installing the GC 1
Agilent Intuvo 9000 GC Installation 57
Procedure:
1 Locate the input fitting for inlet coolant on the back of the
GC. Prepare enough tubing to reach from the supply to this
outlet.
2 Connect the supply tubing to the air supply outlet with the
fitting recommended by the supplier.
3 Use a Swagelok fitting to connect the supply tubing to the
cryogenic valve input fitting.
,QOHWFU\RFRROLQJÀWWLQJ
