Installing the GC 1
Agilent Intuvo 9000 GC Installation 71
Remove the packing materials
1 Open the GC front door.
2 Remove the bus door.
3 Open the oven door.
4 Remove the column plug and gasket.
a Remove the compression bolts using the torque driver.
b Remove the plug and discard.
c Remove and discard the gasket.
Figure 11 Remove the column plug
Compression
bolts
Gasket
Plug
