54 Agilent Intuvo 9000 GC Installation
1 Installing the GC
Procedure:
1 Locate the inlet for liquid CO
2
on the back of the GC.
2 Prepare enough tubing to reach from the supply tank to this
fitting.
3 Connect the supply tubing to the liquid CO
2
tank outlet with
the fitting recommended by the supplier.
4 Use a Swagelok fitting to connect the supply tubing to the
cryogenic valve inlet.
Connecting liquid nitrogen
,QOHWFU\RFRROLQJÀWWLQJ
Liquid nitrogen is a hazard because of the extremely low
temperatures and high pressures that may occur in improperly
designed supply systems.
Liquid nitrogen can present an asphyxiation hazard if vaporizing
nitrogen displaces oxygen in the air. Consult local suppliers for
safety precautions and design information.
See the Intuvo 9000 GC, GC/MS, and ALS Site Preparation Guide
for important requirements for tubing.
