Agilent Technologies Intuvo 9000 User Manual

108 Agilent Intuvo 9000 GC Installation
B Cabling Diagrams and Remote Start/Stop
Agilent APG remote start/stop cable, 03396-61010
Synchronizes the GC with an Agilent integrator. Additional
cables may be used to add more instruments (up to 10 total).
Figure 25 Remote start/stop cable, GC to Agilent integrator
Agilent APG remote start/stop cable, G1530-60930
Synchronizes the GC with another Agilent instrument.
Additional cables may be used to add more instruments (up to
10 total).
Figure 26 Remote start/stop cable, GC to Agilent instrument
8 Yellow Stop (low tone)
9 Violet Open circuit
Table 10 Remote start/stop cable connections (continued)
Connector 1, 9-pin male Connector 2, wire color Signal
6
9
1
5
5
1
9
6
G1530-60930
9
6
5
1
1
2
