2 General Power Meter Functions
94 N1913/1914A EPM Series Power Meters User’s Guide
VGA Output (Optional)
The VGA output is used to project the meter’s small display to a bigger
monitor or screen. This VGA output feature is available as an orderable
option.
The VGA output ON/OFF selection is provided via the front panel and
SCPI. The default setting is OFF.
To access the VGA output selection,
1 Press , and select .
2 In the Service menu, press and select .
3 Press to toggle ON/OFF the VGA feature (see Figure 2- 59).
Figure 2-59 VGA toggle ON/OFF
1 of 2
Service
1 of 2
Display
Display
