Using U2000 Series USB Power Sensors 7
N1913A/1914A EPM Series Power Meters User’s Guide User’s Guide 173
Now, set the frequency of the signal you want to measure. The power
meter automatically selects the appropriate calibration factor.
4 Press . On dual channel meters select the required channel.
5 Use the and keys to highlight the Frequency value field
and press to display the Frequency pop- up. Use the numeric
keypad to enter the required value in the Frequency pop- up window.
Figure 7-3 Frequency pop-up
6 Confirm your choice by pressing or .
7 Press key to close the Channel Setup screen.
8 Proceed to make the measurement.
9 Reconnect any required attenuators or adaptors and connect the power
sensor to the signal to be measured.
The corrected measurement result is displayed.
