Introduction 1
Agilent N1913/1914A EPM Series Power Meters User’s Guide 23
Figure 1-9 Password security dialog box
Click the Submit (accept the default password) and the window opens as
shown in Figure 1- 10. The default password is “agilent”.
A LAN reset needs to be performed to ensure that the password is reset to default. See
LAN reset procedure as below.
Procedure:
1 Press , to display the Remote Interfaces screen.
2 Press softkey to display the second page of the Remote I/F menu.
3 Press softkey to reset the LAN settings to default.
When softkey is pressed, it will also change the GPIB address to default.
You can change the password from the Configuring your N1914A Power Meter window as
shown in Figure 1-10. Scroll down the Parameter column until you locate the Change
Password parameter.
