2 General Power Meter Functions
66 N1913/1914A EPM Series Power Meters User’s Guide
Numeric Format
Configure a measurement displayed in or
format as follows:
• Press , to select the measurement window or
measurement line you want to configure.
Figure 2-27 Measurement Setup showing single configuration
Single Numeric
Dual Numeric
Meas Select
Selected Window/
Function Field
Measurement Field
Measurements
Channel Field
