2 General Power Meter Functions
46 N1913/1914A EPM Series Power Meters User’s Guide
Enter (or edit) the frequency and offset pairs as follows:
1 Press to add a new frequency value (or press to edit).
Use the numeric keypad to enter the required value in the Frequency
pop- up window. Complete the entry by pressing the , keys.
2 Enter the new offset value (or press to edit). Use the numeric
keypad to enter the required value in the Offset pop- up window.
Complete the entry by pressing the key.
Figure 2-12 Changing offset unit
3 Continue adding/editing values until you have entered all the data you
require.
4 When you have finished editing the table press to save the table.
The following rules apply to naming sensor calibration tables:
• The name must consist of no more than 12 characters.
• All characters must be upper or lower case alphabetic characters, or numeric (0-9), or
an underscore (_).
• No other characters are allowed.
• No spaces are allowed in the name.
