General Power Meter Functions 2
N1913/1914A EPM Series Power Meters User’s Guide 47
Selectable Frequency Dependent Offset Unit (dB or %)
The offset in dB range is from –100 dB to +100 dB.
The equivalent range in % is from 0.0000000001% to 10000000000%.
Once the offset unit is selected, it will be applied to all the offsets in the
selected table and also to the remaining nine tables.
To change the offset unit to dB, press , , and .
To change the offset unit to %, press , , and .
If you measure a signal with a frequency outside the frequency range defined in the
frequency dependent offset table, the power meter uses the highest or lowest frequency
point in the frequency dependent offset table to calculate the offset
