Agilent Technologies U1253B - Frequency Sensitivity During Current Measurement; Table 7-10 Sensitivity for Current Measurement

184 U1253B User’s and Service Guide
7 Specifications
[1]
Maximum input for specified accuracy = 10 × range or 1000 V.
Frequency sensitivity during current measurement
[1]
For maximum input, please refer to AC current measurement.
[2]
The accuracy for duty cycle and pulse width is based on a
5 V square wave input to the DC 5 V range. For AC coupling, the duty cycle
range can be measured within the range of 5% to 95% for signal frequency
> 20 Hz.
500 V 30 V, < 100 kHz No spec. 60 V No spec.
1000 V 50 V, < 100 kHz No spec. 120 V No spec
Table 7- 9 Frequency sensitivity and trigger level
Input range
[1]
Minimum sensitivity
(rms sine wave)
Trigger level for DC
coupling
20 Hz to 200 kHz
> 200 kHz to
500 kHz < 100 kHz
> 100 kHz to
500 kHz
Table 7- 1 0 Sensitivity for current measurement
Input range
Minimum sensitivity (rms sine wave)
20 Hz to 20 kHz
500 μA100 μA
5000 μA250 μA
50 mA 10 mA
440 mA 25 mA
5 A 1 A
10 A 2.5 A
