Functions and Features 3
U1253B User’s and Service Guide 71
Data Logging
The data logging function provides the convenience of
recording test data for future review or analysis. Since data
is stored in nonvolatile memory, the data remains saved
when the multimeter is turned OFF or the battery is
changed.
The two options offered are manual (hand) logging and
interval (time) logging functions, which is determined in the
Setup mode.
Data logging records the values on the primary display only.
Manual logging
First of all, ensure that manual (hand) logging is specified in
Setup mode.
1 Press for more than 1 second to store the present
value and function on the primary display in the meters
memory. and the logging index are displayed for 3
seconds.
2 Press and hold again for the next value that you
would like to save into the memory.
To use the data logging function, you will need to connect the multimeter
to a PC using the U1173A IR-to-USB cable (purchased separately) and
download the data logging software from Agilent’s website. Please go to:
http://www.agilent.com/find/hhTechLib to download the software.
