Table 1-10 Terminal connections for different measurement functions
Rotary switch position Input terminals Overload protection
COM
1000 Vrms
1000 Vrms
for short circuit <0.3 A
μA.mA COM
440 mA/1000 V, 30 kA
fast-acting fuse
ACOM
11 A/1000V, 30kA
fast-acting fuse
COM
COM
440 mA/1000 V
fast-acting fuse
