Getting Started Tutorial 1
U1253B User’s and Service Guide 3
• Agilent GUI Application Software (the IR- USB cable is
sold separately).
• Closed case calibration.
• 50,000- count precision true RMS digital multimeter,
designed to meet EN/IEC 61010- 1:2001 Category III
1000 V/ Category IV 600 V, Pollution Degree 2 standards.
Adjusting the tilt-stand
To adjust the multimeter to a 60° standing position, pull the
tilt- stand outward to its maximum reach.
Figure 1-1 Tilt-stand at 60°
IR-USB cable
To P C ( h o st )
Tilt-stand at 60
°
