4 U1253B User’s and Service Guide
1 Getting Started Tutorial
To adjust the multimeter to a 30° standing position, bend the
tip of the stand so that it is parallel to ground, then pull the
stand outward to its maximum reach.
Figure 1-2 Tilt-stand at 30°
To adjust the multimeter to a hanging position, flip the
stand upward and over its maximum reach until it is
detached from its hinge. Then flip the stand over so that its
inner surface is facing the rear. Now, press the stand down
into its hinge. Follow the step- by- step pictorial instructions
below.
IR-USB cable
To P C ( h o s t)
Tilt-stand at 60
°
To Next Page
