Agilent Technologies U1253B

188 U1253B User’s and Service Guide
7 Specifications
Operating Specifications
Measurement rate (approximate)
Table 7- 1 7 Measurement rate
Function Times/second
AC V 7
AC V + dB 7
DC V (V or mV) 7
AC V (V or mV) 7
AC+DC V (V or mV) 2
Ω / nS 14
Diode 14
Capacitance 4 (< 100 μF)
DC A (μA, mA, or A) 7
AC A (μA, mA, or A) 7
AC+DC A (μA, mA, or A) 2
Te m p e r a t u r e 6
Frequency 1 (> 10 Hz)
Duty cycle 0.5 (> 10 Hz)
Pulse width 0.5 (> 10 Hz)
