18 U1253B User’s and Service Guide
1 Getting Started Tutorial
[1]
Depends on the relevant setting in the Setup mode.
[2]
Press for more than 1 second to return to AC V measurement only.
(AC+DC current)
(With the positive probe inserted into the μA.mA
terminal)
DC mA
AC mA
AC+DC mA
% (0 mA to 20 mA or 4 mA to 20 mA
[1]
)
(Reading in mA or A is shown as secondary display)
(AC+DC current)
(With the positive probe inserted into the A
terminal)
DC A
AC A
AC+DC A
Duty cycle (%)
Pulse width (ms)
Table 1- 7 Selecting display with the Shift button (continued)
Rotary switch position (Function) Primary display
