Airo X RT Series - 13 Hydraulic Diagram X12 Rtd - X14 Rtd - X12 Rte - X14 Rte

Use and Maintenance Manual - X_RT Series Page 117
13. HYDRAULIC DIAGRAM X12 RTD – X14 RTD – X12 RTE – X14 RTE
1
DISCHARGE FILTER
2
TANK
3
HYDRAULIC BLOCK
4
DOUBLE PUMP
5
PRESSURE GAGE CONNECTION
6.7
DRIVE HYDRAULIC MOTOR
8
LEVELLING JACK HYDRAULIC BLOCK
9
LEVELLING JACK CYLINDER
10
SWING
AXLE CYLINDER
11
OSCILLATING AXLE HYDRAULIC BLOCK
12
STEERING CYLINDER
13
LOWERING CONTROL INTEGRATED ASSEMBLY
14
LIFTING CYLINDER
15
SUCTION FILTER
16
HIGH/LOW SPEED HYDRAULIC BLOCK
EV1
PROPORTIONAL SOLENOID VALVE
EV2
FORWARD DRIVE
SOLENOID VALVE
EV3
BACKWARD DRIVE SOLENOID VALVE
EV4
LIFTING SOLENOID VALVE
EV5A/B
LOWERING SOLENOID VALVE
EV8
LEFT STEERING SOLENOID VALVE
EV9
RIGHT STEERING SOLENOID VALVE
EV10A/B
2WD/4WD DRIVE SOLENOID VALVE
EV10C/D
DIFFERENTIAL LOCK
SOLENOID VALVE
EV11A
BY
-
PASS SOLENOID VALVE
EV11B
HIGH/LOW SPEED SOLENOID VALVE
EV21÷28
LEVELLING JACK CYLINDER SOLENOID VALVES
EV41A/B
SWING AXLE SOLENOID VALVE
FD1/2
FLOW DIVIDER
MD
DIESEL MOTOR
ME
ELECTRIC MOTOR
HP
EMERGENCY MANUAL DRIVE
PUMP
OM1
EMERGENCY MANUAL DRIVE OPERATOR
VPR
STEERING PRIORITY VALVE.
