Airo X RT Series - Hydraulic Circuit Oil Level Check and Change

Use and Maintenance Manual - X_RT Series Page 61
7.3.4 Hydraulic circuit oil level check and change
Check the level periodically by means of the provided indicator
(detail A in the picture aside) and make sure that the level always lies
between the max. and min. values. If necessary top up until max.
level is reached. The oil check should be carried out when
platform is completely lowered and levelling outriggers fully
raised (if any).
Completely change the hydraulic oil at least every two years.
To empty the tank:
 Lower the platform completely.
 Retract the outriggers completely (if present).
 Stop the machine by pressing the emergency stop
button of the ground control panel.
 Place a container under cap (B), under the tank, and
unscrew it.
Use only the types of oil and quantity indicated in the table below.
HYDRAULIC SYSTEM OIL
BRAND
TYPE
-20°C +79°C
TYPE
-30°C +48°C
REQUIRED QUANTITY
SYNTHETIC OILS
See chapter "Technical features".
ESSO
Invarol EP46
Invarol EP22
AGIP
Arnica 46
Arnica 22
ELF
Hydrelf DS46
Hydrelf DS22
SHELL
Tellus SX46
Tellus SX22
BP
Energol SHF46
Energol SHF22
TEXACO
Rando NDZ46
Rando NDZ22
Q8
LI HVI 46
LI HVI 22
PETRONAS
HIDROBAK 46 HV
HIDROBAK 22 HV
BIODEGRADABLE OILS
-
OPTIONAL
PANOLIN
HLP SINTH E46
HLP SINTH E22
Do not dispose of used oil in the environment. Comply with the current local standards.
The lubricants, hydraulic oils, electrolytes and all detergent products should be handled with care and disposed of in safety
according to the current regulations. A prolonged contact with the skin may cause irritations and dermatosis; wash with water and
Fig. 23
A
B
