Use and Maintenance Manual - X_RT Series Page 35
5.1.6.3 Heat engine start button (models” D”, “ED”, “B”, EB”)
It starts the heat engine (Diesel or Petrol) on dual-powered models (ED or EB) and on thermal-powered models (D or B). With
selector H in position THERMIC operating the switch G:
In START position it enables starting.
In position 3 sec it pre-heats the plugs (motors with plugs only).
In position 0 it stops the heat engine.
5.1.6.4 Manual horn
It warns that the machine is moving. It is manually operated by means of the press-button M.
5.1.6.5 Emergency stop button
By pressing the red STOP button N all control functions are interrupted. Normal functions are enabled by rotating the button of 1/4
turn clockwise.
5.1.6.6 Secondary safety system “S.A.F.E.” (OPTIONAL)
S.A.F.E. (Self Adjustment From Entrapment) is a secondary safety system that reduces to a minimum the risk of the operators
being crushed while working in narrow spaces and limited by height. With the S.A.F.E. system the operator on the platform can limit
the maximum working height by avoiding as far as possible any impacts while the platform is lifting.
To limit the maximum working height the operator must lift the platform up to the desired height and, after making sure he is safe
from any risks, with machine ON and at a standstill, he has to save this height by pressing button ZE for at least 5 seconds, until
the warning light built-in the button turns on and an audible double beep is produced by the platform. The acquired position
becomes the maximum lifting limit and the platform will limit its maximum height up to the limit set even after the machine is turned
on and off several times.
To disable the system and return to use the machine up to the maximum possible height, press button again ZE for at least 5
seconds until the warning light built-in the button turns off.
WARNING!
The S.A.F.E. system is not a safety system, but an aid to the platform operator who should be in any case
trained in the use of the machine and able to recognize any residual risks related to the working
environment.
