Use and Maintenance Manual - X_RT Series Page 59
7.3.2 Greasing
Grease all articulated joints equipped with greaser
(or predisposition for greaser) at least every
month.
At least once a month, using a spatula or a brush,
lubricate the sliding guides of the:
a) Sliding blocks/rolls of the extensible
structure on the chassis.
b) Sliding blocks/rolls of the extensible
structure under the platform.
c) Counter-pressure sliding blocks/rolls of
the mobile platform.
At least once a month lubricate:
d) The support pins of the steering wheels
equipped with greaser.
e) The pivots of the oscillating axle.
f) The supports of the levelling jack
cylinders.
Moreover, remember to grease the articulated
joints in the following cases:
After washing the machine.
Before using the machine again after a long time-interval.
After using the machine in adverse environmental conditions (high humidity levels; presence of dust; coastal areas, etc).
Before greasing, clean thoroughly using a wet cloth. Grease all points indicated in the picture aside (and all articulated joints
equipped with greaser) with grease type:
ESSO BEACON-EP2
or similar.
(OPTIONAL BIODEGRADABLE OIL KIT)
PANOLIN BIOGREASE 2
Fig. 21
