Airo X RT Series - Model X12 RTE

Use and Maintenance Manual - X_RT Series Page 14
2.2 Model X12 RTE
Dimensions: X12 RTE
Maximum working height
-
STANDARD
12.15
m
39 ‘8”
ft
Maximum working height
-
WITH
LEVELLING OUTRIGGERS (OPTIONAL)
12.45
m
40 ‘8”
ft
Max. platform height
-
STANDARD
10.15
m
33 ‘3”
ft
Max. platform height
-
WITH LEVELLING OUTRIGGERS (OPTIONAL)
10.45
m
34 ‘2”
ft
Ground clearance
280
mm
11 ’0”
in
Platform height for safety
speed activation
2.5
m
8 ‘2”
ft
Internal steering radius
2.4
m
7 ‘8”
ft
External steering radius
4.7
m
15 ‘4”
ft
Maximum capacity (m)
450
Kg
990
lbs
Maximum amount of people on platform (n)
3
3
Tool and material weight (me)
210
Kg
463
lbs
Maximum slide
-
out extension deck
1.5
m
4 ‘9”
ft
Maximum capacity with platform extended
450
Kg
990
lbs
Max. No. of people with platform extended
3
3
Maximum drive height
Max
Max
Maximum
platform dimensions (extended)
1.6 x 3.9
m
4 ‘9” x 12 ‘7”
ft
Max. hydraulic pressure
240
Bar
3480
psi
Max. pressure of lifting circuit
180
Bar
2611
psi
Min. pressure of braking circuit
50 ÷ 60
Bar
725 ÷ 870
psi
Tyre dimensions (****)
Ø 650 x 300
mm
25.5” x 11.8”
in
Tyre type (****)
26 x 12
–
12
26 x 12
–
12
Transport dimensions with rails installed
-
STANDARD
2,64 x 1,8
H=2,54
m
8 ‘5”x 5 ‘9”x 8 ‘3”
ft
Transport dimensions with rails installed
-
WITH LEVELLING OUTRIGGERS
(OPTIONAL)
3,04 x 1,8
H=2,54
m
9 ‘9”x5 ‘9”x 8 ‘3”
ft
Transport dimensions with rails folded down
-
STANDARD
2,64 x 1,8
H=1,85
m
8 ‘5”x 5 ‘9”x5 ‘9”
ft
Transport dimensions with rails folded down - WITH LEVELLING OUTRIGGERS
(OPTIONAL)
3,04 x 1,8
H=1,85
m
9 ‘9”x5 ‘9”x5 ‘9”
ft
Machine weight (unloaded)
-
STANDARD (*)
4230
Kg
9300
lbs
Machine weight (unloaded)
-
WITH LEVELLING OUTRIGGERS (optional) (*)
4580
Kg
10000
lbs
Stability limit:
Longitudinal inclination
3
°
3
°
Transversal inclination
2.5
°
2.5
°
Maximum wind speed (***)
12.5
m/s
28
mph
Maximum manual force:
400
N
90
lbf
Max. load per wheel
-
STANDARD (*)
2215
Kg
4880
lbs
Max. load per wheel
-
WITH LEVELLING OUTRIGGERS (OPTIONAL) (*)
2390
Kg
5200
lbs
Performance:
Drive wheels
4
N
4
N
Max. drive speed
4.5
km/h
2.8
mph
Safety drive speed
0.4
km/h
0.3
mph
Lowering/lifting time (unloaded)
40
-
45 / 55
-
60
Sec.
40
-
45 / 55
-
60
Sec
Oil tank capacity
80
Lt.
21
gal
Gradeability
35
%
35
%
Max.
operating temperature
+50
°C
122
°F
Min. operating temperature
-
15
°C
5
°F
Battery power
Standard battery capacity and voltage
48 / 315 (c5)
V/Ah
48 / 315 (c5)
V/Ah
Total electrolyte quantity of standard battery
24 x 5,4
Litri
6.3 x 1.4
gal
Standard battery weight
528
Kg
1164
lbs
Single
-
phase battery charger (HF)
48 / 45
V/A
48 / 45
V/A
Battery charger mains voltage
-
single phase
230
–
50
V
-
Hz
230
-
50
V
-
Hz
Max. current absorbed by the battery charger
15
A
15
A
Max.
installed power
12
kW
16
hp
AC electric pump power
12
kW
16
hp
Max. absorbed current
300
A
300
A
