6.3 Emergency towing of the machine
In the event of a fault, carry out the following operations to
tow the machine:
 Hook the machine to the provided holes (the same used
for lifting – see previous pictures).

Screw knob B completely on the hydraulic block.

Activate the manual pump until the control is bound; by doing
so the parking brakes are unlocked.
 Tow at a very slow speed (remember that when the
machine is being towed, brakes are out of order).
At the end of towing operation, resume initial conditions:
 Pull out knob B.
T
ype
1:
Type 2:
Fig. 17
Tow at a very slow speed (remember that when the
machine is being towed, brakes are out of order).
Tow only on a flat ground.
Do not park the machine without brakes on. Should the brakes be completely out of order put wedges
under the wheels to prevent the machine from moving accidentally.
B
A
B
A
