Airo X RT Series - Model X14 RTD

Use and Maintenance Manual - X_RT Series Page 16
2.3 Model X14 RTD
Dimensions: X14 RTD
Maximum working height
-
STANDARD
14
m
45 ‘9”
ft
Maximum working height
-
WITH LEVELLING OUTRIGGERS (OPTIONAL)
14.3
m
46.9”
ft
Max. platform height
-
STANDARD
12
m
39 ‘3”
ft
Max. platform height
-
WITH LEVELLING OUTRIGGERS (OPTIONAL)
12.3
m
40 ‘3”
ft
Ground clearance
280
mm
11”
in
Platform height for safety speed
activation
2.5
m
8 ‘2”
ft
Internal steering radius
2.4
m
7 ‘8”
ft
External steering radius
4.7
m
15 ‘4”
ft
Maximum capacity (m)
400
Kg
880
lbs
Maximum amount of people on platform (n)
3
3
Tool and material weight (me)
160
Kg
462.9
lbs
Maximum slide
-
out extension deck
1.5
m
4 ‘9”
ft
Maximum capacity with platform extended
400
Kg
880
lbs
Max. No. of people with platform extended
3
3
Maximum drive height
10
m
32’
9
”
ft
Maximum platform dimensions (extended)
1.6 x 3.9
m
4 ‘9” x 12 ‘7”
ft
Max. hydraulic pressure
240
Bar
3480
psi
Max. pressure of lifting circuit
210
Bar
3480.9
psi
Min. pressure of braking circuit
50 ÷ 60
Bar
725 ÷ 870
psi
Tyre dimensions
(****)
Ø 650 x 300
mm
25.5” x 11.8”
in
Tyre type (****)
26 x 12
–
12
26 x 12
–
12
Transport dimensions with rails installed
-
STANDARD
2,64 x 1,8
H=2,67
m
8 ‘5”x 5 ‘9”x 8
‘3”
ft
Transport dimensions with rails installed - WITH LEVELLING OUTRIGGERS
(OPTIONAL)
3,04 x 1,8
H=2,67
m 9 ‘9”x5 ‘9”x 8
‘3”
ft
Transport dimensions with rails folded down
-
STANDARD
2,64 x 1,8
H=1,98
m
8 ‘5”x 5 ‘9”x 6
‘4”
ft
Transport dimensions with rails folded down - WITH LEVELLING OUTRIGGERS
(OPTIONAL)
3,04 x 1,8
H=1,98
m 9 ‘9”x5 ‘9”x 6
‘4”
ft
Machine weight (unloaded)
-
STANDARD (*)
4180
Kg
9200
lbs
Machine weight (unloaded)
-
WITH LEVELLING OUTRIGGERS (optional) (*)
4530
Kg
9900
lbs
Stability limit:
Longitudinal
inclination
2
°
2
°
Transversal inclination
1
°
1
°
Maximum wind speed (***)
12.5
m/s
28
mph
Maximum manual force:
400
N
90
lbf
Max. load per wheel
-
STANDARD (*)
2290
Kg
5000
lbs
Max. load per wheel
-
WITH LEVELLING OUTRIGGERS
(OPTIONAL) (*)
2450
Kg
5400
lbs
Performance:
Drive wheels
4
N
4
No
Max. drive speed
4.5
km/h
2.8
mph
Safety drive speed
0.4
km/h
0.3
mph
Lowering/lifting time (unloaded)
40
-
45 / 55
-
60
Sec.
40
-
45 / 55
-
60
Sec
Oil tank capacity
80
Lt.
21
gal
Gradeability
30
%
35
%
Max. operating temperature
+50
°C
122
°F
Min. operating temperature
-
15
°C
5
°F
