Use and Maintenance Manual - X_RT Series Page 42
5.4.1 Heat engine start-up
By turning the starter key on the platform control panel:
To “0” position the Diesel engine stops (models “D” and “ED”).
To “3 sec” position the plugs pre-heating takes place (only engines with plugs) (models “D” and “ED”).
To “Start” position the motor starts.
Do not insist on the starting position for longer than 3
seconds. In the event of failed start, check the fuel level
by means of the relevant indicator and read the Use and maintenance manual of the Engine.
Do not try to start the motor if it is already running. This operation may cause the pinion of the starter to break
(under normal conditions the control system blocks this operation).
In the event of operational faults, check the motor warning lights and read the Use and Maintenance manual of
the motor.
NOTE: The Diesel engine can be started only if the plat
form green warning light ON is flashing.
5.4.2
Starting the 230V single-phase electric pump (OPTIONAL)
powered models can be equipped, on request, with a
230V electric pump.
To start the electric pump:
1)
Insert the 230 V plug of the power cable into the socket (A).
2)
Set the switch (B) shown in figure to ON position.
3) To start the electric pump with the platform controls:
Select the on-platform control panel by means of the
locking key switch located on the electric control unit
on the chassis.
Unlock the push-button turning by a ¼ of turn
clockwise.
Set the power selector at platform to "Electric"
position.
Set the power selector at platform (if any) to "230V"
position.
Operate the machine.
NOTE The operations carried out with 230V electric pump
are slightly slower than those with diesel motor.
Fig. 10
WARNING!! Always check the position of the power cord during the movements.
Disconnect all electric power supplies before opening the boxes.
