Airo X RT Series - 2 Technical Features of Standard Machines; Model X12 RTD

Use and Maintenance Manual - X_RT Series Page 12
2. TECHNICAL FEATURES OF STANDARD MACHINES
THE TECHNICAL FEATURES OF THE PRODUCTS IN THE FOLLOWING PAGES CAN BE MODIFIED
WITHOUT PRIOR NOTICE
2.1 Model X12 RTD
Dimensions: X12 RTD
Maximum working height
-
STANDARD
12.15
m
39 ‘8”
ft
Maximum working height
-
WITH LEVELLING OUTRIGGERS (OPTIONAL)
12.45
m
40 ‘8”
ft
Max. platform height
-
STANDARD
10.15
m
33 ‘3”
ft
Max. platform height
-
WITH LEVELLING OUTRIGGERS
(OPTIONAL)
10.45
m
34 ‘2”
ft
Ground clearance
280
mm
11”
in
Platform height for safety speed activation
2.5
m
8 ‘2”
ft
Internal steering radius
2.4
m
7 ‘8”
ft
External steering radius
4.7
m
15 ‘4”
ft
Maximum capacity (m)
450
Kg
990
lbs
Maximum amount of people on platform (n)
3
3
Tool and material weight (me)
210
Kg
463
lbs
Maximum slide
-
out extension deck
1.5
m
4 ‘9”
ft
Maximum capacity with platform extended
450
Kg
990
lbs
Max. No. of people with platform
extended
3
3
Maximum drive height
Max
Max
Maximum platform dimensions (extended)
1.6 x 3.9
m
4 ‘9” x 12 ‘7”
ft
Max. hydraulic pressure
240
Bar
3480
psi
Max. pressure of lifting circuit
180
Bar
2610
psi
Min. pressure of braking circuit
50 ÷
60
Bar
725 ÷ 870
psi
Tyre dimensions (****)
Ø 650 x 300
mm
25.5” x 11.8”
in
Tyre type (****)
26 x 12
–
12
26 x 12
–
12
Transport dimensions with rails installed - STANDARD 2,64 x 1,8
H=2,54
m 8 ‘5”x 5 ‘9”x 8
‘3”
ft
Transport dimensions with rails installed - WITH LEVELLING OUTRIGGERS
(OPTIONAL)
3,04 x 1,8
H=2,54
M 9 ‘9”x5 ‘9”x 8
‘3”
ft
Transport dimensions with rails folded down
-
STANDARD
2,64 x 1,8
H=1,85
M
8 ‘5”x 5 ‘9”x5
‘9”
ft
Transport dimensions with rails folded down - WITH LEVELLING OUTRIGGERS
(OPTIONAL)
3,04 x 1,8
H=1,85
M
9 ‘9”x5 ‘9”x5 ‘9”
ft
Machine weight (unloaded)
-
STANDARD (*)
3980
Kg
8700
lbs
Machine weight (unloaded)
-
WITH LEVELLING OUTRIGGERS (optional) (*)
4330
Kg
9500
lbs
Stability limit:
Longitudinal inclination
3
°
3
°
Transversal inclination
2.5
°
2.5
°
Maximum wind speed (***)
12.5
m/s
28
mph
Maximum manual force:
400
N
90
lbf
Max. load per wheel
-
STANDARD (*)
2215
Kg
4880
lbs
Max. load per wheel
-
WITH LEVELLING
OUTRIGGERS (OPTIONAL) (*)
2390
Kg
5200
lbs
Performance:
Drive wheels
4
N
4
No
Max. drive speed
4.5
km/h
2.8
mph
Safety drive speed
0.4
km/h
0.3
mph
Lowering/lifting time (unloaded)
40
-
45 / 55
-
60
Sec.
40
-
45 / 55
-
60
Sec
Oil tank
capacity
80
Lt.
21
gal
Gradeability
35
%
35
%
Max. operating temperature
+50
°C
122
°F
Min. operating temperature
-
15
°C
5
°F
