Page 19 Commercial in Confidence UWB-D00111 Rev L
5.725 – 5.875 GHz in TDD mode ¾ 2.5 MHz
¾ 5 MHz
¾ 10 MHz
5.850 – 5.950 GHz in TDD mode ¾ 2.5 MHz
¾ 5 MHz
¾ 10 MHz
2.1.1 Main Features
The ProST provides the following main features:
¾ Full Outdoor Non-LOS Deployment: 256 FFT
¾ Based on the latest wireless technology WiMAX IEEE 802.16 standard
¾ Integrated antenna gain of 16 dBi
¾ Indoor Ethernet adapter (SDA-1 Type II):
¾ Providing power and interface termination
¾ Up to 100-m Category 5e cable between ProST and SDA-1
¾ Indoor:
SDA-4S Type II: small low cost IDU with built in LAN switch
SDA-4SDC Type II: small low cost DC IDU with built in LAN Switch
SDA-WiFi: Optional WiFi module -- an extension module allowing you to add WiFi
functionality to your ProST unit(s)
SDA-MSG (Multi-Service Gateway): Optional VoIP module -- an extension module
allowing you to add VoIP functionality to your ProST unit(s).
¾ High throughput providing fast access at burst data rates up to 37 Mbps over-the-air
(gross rate) over up to a 10 MHz channel
¾ Option of LAN switch with indoor adapter
¾ Up to 4 ports with VLAN port switching
¾ Supports multiple UL bursts per SS frame
¾ Signal information can be obtained via Web Management Performance tool
¾ Integral WiFi and LAN switch
Note: Contact your Airspan representative for more information on the SDA-
MSG VoIP extension module or the SDA-WiFi extension module.
2.2 ProST-2 Frequency Ranges
The table below lists the frequency range of ProST-2, TDD/FDD Multimode models currently
available. This table will grow as more models become available.
Figure2‐ProST‐2FrequencyRanges
Frequency Band Channel Bandwidth
