ProST Hardware Installation User Guide 

Page 20 Commercial in Confidence UWB-D00111 Rev L
3.4 – 3.6 GHz in TDD/FDD 50/100 mode
1.75 MHz
2.75 MHz
3.5 MHz
5 MHz
7 MHz
10 MHz
3.6 – 3.8 GHz in TDD/FDD 50/100 mode
1.75 MHz
2.75 MHz
3.5 MHz
5 MHz
7 MHz
10 MHz
Note: These ProST-2 Frequencies do not support the older type RSSI plug.
2.2.1 Main Features
The ProST-2 provides the following main features:
¾ New CPE variants are equipped with Rosedale 2 chipset enabling FDD/TDD multimode
operation, supporting 5 MHz and 7 MHz in both TDD and HFDD modes.
¾ Full Outdoor Non-LOS Deployment: 256 FFT
¾ Based on the latest wireless technology WiMAX IEEE 802.16 standard
¾ Integrated antenna gain of 16 dBi
¾ Indoor Ethernet adapter (SDA-1 Type II):
¾ providing power and interface termination
¾ up to 100-m Category 5e cable between ProST and SDA-1
¾ Indoor:
SDA-4S Type II: small low cost IDU with built in LAN switch
SDA-4SDC Type II: small low cost DC IDU with built in LAN Switch
SDA-WiFi: Optional WiFi module -- an extension module allowing you to add WiFi
functionality to your ProST-2 unit(s).
SDA-MSG (Multi-Service Gateway): Optional VoIP module -- an extension module
allowing you to add VoIP functionality to your ProST-2 unit(s).
¾ High throughput providing fast access at burst data rates up to 37 Mbps over-the-air
(gross rate) over up to a 10 MHz channel
¾ Option of LAN switch with indoor adapter
¾ Up to 4 ports with VLAN port switching
¾ Supports multiple UL bursts per SS frame
¾ Signal information can be obtained via Web Management Performance tool
¾ Integral WiFi and LAN switch
