ProST Hardware Installation User Guide 

Page 30 Commercial in Confidence UWB-D00111 Rev L
This section provides the following SDA-1 physical descriptions:
¾
1Dimensions
¾
1Ports
¾
1LED
4.2.1 Physical Dimensions
The SDA-1 physical dimensions are described in the table below:
Table6‐SDA‐1Dimensions
Parameter Value
Dimensions (L x W x H)
72 x 42.5 x 26 mm (2.83 x 1.67 x 1.02 inches)
Weight
0.159 kg
4.2.2 Ports
The SDA-1 provides two ports, as described in the table below:
Table7–SDA‐1ports
Port Label Interface
8-pin RJ-45 RADIO 10/100BaseT with ProST radio
8-pin RJ-45 LAN/PC 10/100BaseT with subscriber's network
4.2.3 LED
The SDA-1 provides a green power LED (labeled POWER), located on its front panel. This LED
light not only indicates the presence of power, but also can indicate incorrect SDA-1 port
assignment for the network cables, i.e. from the ProST and computer. For a detailed description
of the POWER LED, see
1Troubleshooting.
4.3 SDA-4S Type II and SDA-4S/VL Type II (Optional)
Note: The SDA-4S Type II and the SDA-4SDC are physically (externally) the
same other than the power socket.
The SDA-4S Type II and SDA-4S/VL Type II indoor units (hereafter referred to as SDA-4S) are
two optional integrated LAN switches that offer an alternative to the SDA-1 Type II unit. These two
units have identical physical dimensions and design, as displayed in the figure below.
