ProST Hardware Installation User Guide
Page 28 Commercial in Confidence UWB-D00111 Rev L
4 Physical Description
This section provides a description of the components of the ProST installation:
¾
1ProST radio (outdoor unit)
¾
1SDA-1 adapter (indoor unit -- switch and power interface)
¾
1SDA-4S Type II and SDA-4S/VL Type II adapters (optional)
¾
1SDA-4SDC Type II (indoor DC unit) (optional)
4.1 ProST Physical Description
The ProST is an encased outdoor radio providing access to communication ports on its bottom
panel. The ProST's back panel provides holes for ProST mounting.
This subsection provides the following ProST physical descriptions:
¾
1Dimensions
¾
1Ports
4.1.1 Physical Dimensions
The table below lists the physical dimensions of the ProST.
Table5‐ProSTDimensions
Parameter Value
Dimensions (H x W x D) 311 x 244 x 65.5 mm (12.24 x 9.6 x 2.57 inches)
Weight 1.94 kg (approximate)
4.1.2 Port
The ProST provides a 15-pin D-type port for interfacing with the SDA-1. For convenience, a
DB15-to-RJ45 adapter is supplied for attaching to the 15-pin D-type port to allow the use of RJ-45
connectors for outdoor-to-indoor CAT 5E connectivity.
For ProST models implementing third-party external antennas, an
1N-type port is also provided on
the bottom panel.
