Airspan ProST - SDA-1 Physical Description

ProST Hardware Installation User Guide 

Page 29 Commercial in Confidence UWB-D00111 Rev L
Figure11‐ProSTports
Note: ProST models that use third-party external antennas provide an N-type
receptacle for attaching an external antenna.
4.2 SDA-1 Physical Description
The SDA-1 is an integrated Ethernet and AC/DC power supply adapter that simply plugs into a
standard electrical wall outlet (110/240 VAC). The SDA-1 enables easy plug prong replacement to
suit geographical location of electrical outlet sockets (e.g. American vs. European).
The SDA-1 provides the ProST with the following interfaces:
¾ 10/100BaseT interface with subscriber's network/PC
¾ 10 to 52 VDC power supply
The SDA-1 physical description is shown in the figure below:
Figure12‐SDA‐1
