ProST Hardware Installation User Guide
Page 21 Commercial in Confidence UWB-D00111 Rev L
Note: Contact your Airspan representative for more information on the SDA-
MSG VoIP extension module or the SDA-WiFi extension module.
2.3 Architecture
The ProST installation consists of the following components:
Encased ProST outdoor unit (
1available in two variations)
SDA-1 indoor adapter or optional SDA-4S Type II, SDA-4S/VL Type II, or SDA-4S/DC
Type II
Third-party external antenna (optional deployment)
Note: The SDA-1 Type II adapter can also be implemented with other
Airspan's products (i.e. BSR, PPR, and SPR). For further information
regarding these products, please contact your nearest Airspan dealer.
The figure below displays a typical architecture setup of the ProST with an integrated antenna.
.
Figure3‐TypicalSetup
2.4 Models
The ProST is available in the following variations, differing in antenna configuration:
¾ ProST with built-in (integrated), flat-panel antenna
