Alde Compact 3010 Operating And Installation Instructions

17
US/CAN
Functions of the control panel:
A.ElectricalcartridgeOFF.
B.Electricalcartridgeno.1ONat950W
C.Electricalcartridgeno.2ONat950W
D.Electricalcartridgeno.1and2ONattotal1900W
E.LPgasburnerOFF.
F.LPgasburnerON.
G.RedLEDashesifthevoltagetotheboilergoesbelow
10,5V(automaticresettingathighervoltage).Fixedlight,
theLPGboilerhasbecomeblocked(resettingbythecen-
tralswitchforLPG)oroverheated(resettingbythemain
switchofthevehicle).Thetemperaturesensorsofthe
boilercouldbedefectiveaswell(resettingnotpossible).
H.Electricalcartridge/LPgasboiler/Circulationpump
switchedoff.
I.(Normalmode)CirculationpumpONandcontrolled
bythethermostatonthecontrolpanel.Theoperationof
theelectricalcartridge/LPgasboileriscontrolledbythe
boiler’sbuilt-inthermostat.Thismodeisusedwhenboth
heatandhotwater131°F (55°C)arerequired.
NB! IfboththeelectricalcartridgeandtheLPgasboiler
areON,theelectricalcartridgeheatsuprstandtheLP
gasboileronlystartswhentheroomtemperaturehas
gonedownby2-4°F(1-2°C).
J.Onlyhotwater149°F(65ºC)circulationpumpis
switchedoff.
NB!IfboththeelectricalcartridgeandtheLPgasboiler
areON,onlytheelectricalcartridgeheatsup.
K.Dialforsettingthedesiredroomtemperature.
L.Guideforsettingtheroomtemperaturetoapproxi-
mately72°F(22°C).
Please read these instructions carefully before using the boiler. For Operating and Installation Instructions of
boiler, please see separate instruction. TheseinstructionsareapprovedfortheAldeCompact3010boilerttedin
recreationalvehicles,inaccordancewithANSI21.13-2014,CSA4.9-2014.
Installationandrepairsmayonlybecarriedoutbyaprofessional.Nationalregulationsmustbeadheredto.
OPERATING INSTRUCTIONS CONTROL PANEL 3010 214
A
C
B
D
E
F
G
I
J
H
K
L
