Alde Compact 3010 Operating And Installation Instructions

50
SCHÉMA DU CÂBLAGE DE LA CHAUDIÈRE
5. Heating temp. probe (Blue) 1. Ground (Grey) 2. Ground (Blue) 3. Ground (Red) 4. Sanitary hot water temp. probe (Grey) 6. Overheat temp. probe (Red)
Element neutral (Grey)
Green
Element step 1 (Red)
Igniter
Sensor
(minifit 6 outputs)
Igniter
Green
Supply 110V-N Blue
Sensors
(minifit 4 outputs)
Element step 2 (Black)
Fan
110V Ground
3. Step 2 (Brown)
7. Blue 9-10 Not in use
Additional:
(minifit 10 outputs)
Supply 110V-L Brown
Mechanical panel
12Vdc power supply +
-
(Ground) 12V
Fuse 3.15A
(minifit 2 outputs)
(minifit 10 outputs)
(+) 12V
Fuse 3.15A
3010214
Pump 12Vdc
4. Not in use
3010614 Control panel
2. +5 VDC supply (Red) 1. Ground (Black)
6. Not in use 5. Ground (Black)
(minifit 6 outputs) Solenoid
(minifit 3 outputs) Supply 12Vdc
3. Ground (Black)
1. Ground (Black)
2. Ground (Black) 1. +12Vdc in (Red)
2. Not in use 1. +12Vdc in (Red)
3-6 Not in use
4. Speed information (Blue) 3. +9Vdc regulated supply (Red) 2. Not in use
8. Grey
Low Water Cutoff
1. Step 1 (Blue) 2. PWM output (Brown)
1. Ground 2. +5 VDC supply 3. Hot water only 4. Gas on 5. Lock out information 6. Ambient temp. probe 7. Electric element no.1 950W 8. Electric element no.2 950W 9. Panel configuration 10. Temp. set point 11. External temp. probe 12. External temp. probe
