USING THE BOILER
DOMESTIC HOT WATER
Theheatingsystemcansupplydomestichotwaterusing
eitherLPGasorelectricity.Youmaytemporarilyincrease
thetemperatureofthehotwaterusingthesamethermo-
staticcontrolpanelthatisusedforspaceheating.
Pleaseseethecontrolinstructionsfordetails.
To make hot water with the boiler:
1. MakesurethattheRV:sfreshwatertankislledup
withfreshwaterorconnectedtomainwatersupply.
2. Filltheboilerwithclean,freshwater.Iftheboilerhas
notbeenusedforsometime,ushitoutwithfresh
waterbyopeninganyhotwatertapintheRVandal-
lowingapproximately3gallonstorunthroughthetap.
3. Closealltapsandstarttheheaterusingthe
ControlPanel.
USING ONLY HOT WATER
Whenonlyhotwaterisrequired(forexampleduringthe
summer),nosettingsneedtobechanged.Theboilerwill
lookafterthisfunctionautomatically.
RefertotheControlPanelinstructionsfordetailson
operatinghotwater.
Automatic check valve
Figure 6. Check valve location
Figure 5. Safety/drain valve
Drain valve lever
DANGER
FARA
DANGER
GEFAHR
FARE
VAARA
PELIGRO
PERICOLO
GEVAAR
HOT WATER HAZARD
Hot water at temperatures above 125°F (51ºC) can
cause serious scalding injuries and in extrem cases
even death.
The boiler can deliver hot water at a temperature up
to 185°F (85°C).
– For safe operation, use a mixing valve set at
temperature no higher than 125°F (51°C).
AIR CUSHION
Theboilerisdesignedtohaveanairspace,calledanair
cushion,atthetopofthetank.Thisaircushionisessen-
tialforabsorbingpressuresurgesintheheater,thuspre-
ventingabuild-upofpressurethatcouldcausedamage
topipesandpipejoints.Whentheboilerisincontinuous
use,however,thisaircushiontendstodissipate.
Draining the boiler using the combined safety/drain
valve:
1. Switchoffthefreshwaterpump.ConsultyourRV
owner’smanualtondthelocationofthiscontrol.
2. Openallwatertaps.
3. Openthesafety/drainvalvebyturningthelever
(SeeFigure5).CheckyourRVowner’smanualto
ndthelocationofthesafety/drainvalve.
4. Theboilerwillnowdraindirectlybelowthevehicle
throughthesafety/drainvalvehose.Checkthatall
thewaterisemptiedout(about2-3gallons/7-10
liters).Leavethevalveintheopenpositionuntilthe
nexttimetheheaterisused.
5.
6. Foremptyingspecially-adaptedboilers,aswellas
anyotherfreshwatersystemsinthevehicle,please
refertothemanufacturer’sinstructions.
NOTICE
To maintain the air cushion, the hot water tank
should be emptied approximately once a month,
to ensure that a new air cushion is formed in the
heater. Follow the directions below to drain the
water heater.
NOTICE
Check that the automatic check valve
(see Figure 6) is open and is allowing air to en-
ter the heater when it is being drained, and that
the hose is not blocked.
Closed  Open
Opening safety valve/drain valve
NOTICE
There may be a variation between the temperature
delivered from the water heater and the temperature
at the tap due to water conditions or the length of
pipe to the water heater.
Drain valve lever
WARNING
VARNING
AVERTISSMENT
WARNUNG
ADVARSEL
VAROITUS
ADVERTENCIA
AVVERTENZA
WAARSCHUWING
INJURY / SCALDING INJURY
• Never actuate the drain valve lever as long as the
water heater is still warm.
• Never actuate the drain valve lever as long as the
water heater is under water pressure and/or is still
warm.
