Alde Compact 3010 Operating And Installation Instructions

4
NOTICE
The Compact 3010 heating system is designed to
be used with a thermostat control. This manual
includes instructions for controlling the system
using the Alde Control Panel 3010 614 (See Figure 3),
which is an optional part of the system. If your RV
has a different control system installed, please refer
to the instructions for that system.
TheAldeCompact3010boiler(Figure1)isdesigned
toprovidebothheatanddomestichotwater.Theboiler
includesbothanLPGasburnerandanelectricheating
element,andyoucanusethesystemwitheitherLPgas
orelectricity,orwithboth.Theheatingsystemconsists
oftheboilerunitaswellasanexpansiontank(Figure2),
whichisinstalledatthehighestpointontheRV.Check
withyourRVowner’smanualtodeterminewherethe
expansiontankisinstalled.Theheatingsystemworksby
circulatinghotglycoluidthroughpipesandheatconvec-
tors,similartothehydronicheatingsystemusedinmany
homes.Theboileristtedwitha12-voltelectricalcircula-
tionpumpthatisusedtocirculatetheheateduid.The
heatconvectorslocatedneartheooroftheRVallowair
tobeheatedbythehotuidinthesystem,andthenthe
airrisesandcirculatestoheatthespaceinyourRV.The
boilerisalsottedwithabuilt-inhotboiler(waterheater)
thathasavolumeofapprox.2.5gallons(8.5liters)fresh
water.TheLPGasboilercanproducearound3gallons
(12liters)of104°F(40°C)watereveryhalf-hour.Ifthe
electricheatingelementsareusedinsteadofgasforpow-
eringtheboiler,thecapacityisslightlyless.Youmayuse
theboilertoheattheRVwithoutllingthewaterheater.
OPERATING INSTRUCTIONS BOILER
Min. level of uid in a
cold system.
Figure 1. Alde Compact 3010 Boiler
Figure 2. Expansion tank
CAUTION
OBSERVERA
ATTENTION
VOORZICHTIG
To avoid possible injury or damage to the heating
system, please read and follow these instructions
carefully before installing and / or using the boiler.
CAUTION
OBSERVERA
ATTENTION
VOORZICHTIG
The boiler comes installed with glycol heating uid.
If the uid is drained for any reason, you must
replace it before restarting the heating system.
Damage to the heating system and voiding of your
warranty could result if you attempt to start it with
no or low level of glycol heating uid.
TheseinstructionsareapprovedforTheAldeCompact
3010boilerinstalledinRecreationalVehicles(RVs)as
detailedinStandardANSI21.13-2014,CSA4.9-2014.
ThecontrolsystemallowsyoutoselectLPGas,electric-
ity,orbothastheenergysource.Ifbothelectricityand
gasareselected,thesystemgivesprioritytoelectrical
power
.
Figure 3. Alde Control Panel 3010 614
DANGER
FARA
DANGER
GEFAHR
FARE
VAARA
PELIGRO
PERICOLO
GEVAAR
HOT WATER HAZARD
Hot water at temperatures above 125°F (51 ºC) can
cause serious scalding injuries and in extreme
cases even death.
The boiler can deliver hot water at a temperature up
to 185°F (85°C).
– For safe operation, use a mixing valve set at
temperature no higher than 125°F (51°C).
DESCRIPTION OF THE HEATING SYSTEM
Iftheheatingsystemhasbeenoutofuseforsometime,
checkthelevelofuidintheexpansiontank(SeeFigure2)
beforeattemptingtostartthesystem.
