Alde Compact 3010 Operating And Installation Instructions

23
US/CAN
1
2
3
4
5
6
7
8
9
10
+
B
JP6
JP4
JP1
R30
BZI
EXT
E F (G) (H) I
C8
C23
+
ThecontrolpanelisintendedfortheAldeCompact3010
boiler.
Mounting:
Determinetheplacingofthecontrolpaneltakingintocon-
siderationthelengthofthecablebetweentheboilerand
thepanel.
Thecontrolpanelshouldbeplacedataheightofat
least3,3foot(1meter)abovetheoor,butshouldnotbe
placedtooclosetotheceiling,neithershoulditbeplaced
closetosourcesofheat.
Itshouldnotbeplacedclosetoheat-emittingdetails.The
spacebehindthepanelmustbewellventilatedsothat
theroomthermostatcanworkproperly.
Ifitcannotbeavoidedthatthethermostatisinuencedby
heatsources,anexternaltransducercanbeconnectedto
thepanel.
Maketheholesforthepanelasshowninthegure
below,andmountitwiththeaccompanyingfourscrews.
Anchorthecablewithcableclipssothattheconnector
stripinthepanelisnotsubjectedtoanystrain.
Thecablingshouldbeassembledaccordingtog.1
NB!Usecoverframe3010261whencontrolpanel3010
214istobeinstalledinplaceofcontrolpanel3010213.
NB!Incasearemotesensorhasbeeninstalled,remove
thetemperaturesensorbelowthetemperatureknobKby
meansofcuttingpliers.
Remotesensor
2,9”
4,6”
3,8”
2,5”
0,3”
Makingholes
0,3”
INSTALLATION INSTRUCTIONS
CONTROL PANEL 3010 214
NOTICE
Do not clamp or bind 12 V cables or sensor cables
together with 120 V cables. It is preferable not to
place the cables close to each other. If the cables
are bundled, the risk of shutdown increases.
