Alienware Aurora R13 - Page 32

NOTE: Note the orientation on the hard-drive carrier to replace it correctly.
Steps
1. Align the hard drive with the pins on the hard-drive carrier.
2. Using the tabs on the opposite side, flex open the carrier to insert the pins on the other side.
3. Slide the hard-drive assembly into the hard-drive cage until it snaps into place.
4. Lift the side light bar.
5. Connect the hard-drive data cable and hard-drive power cable to the hard drive.
6. Push the side light bar down.
Next steps
1. Install the
left-side cover.
2. Follow the procedure in After working inside your computer.
32
