Alienware Aurora R13 - Power-Button Board; Removing the Power-Button Board

Steps
1. Place the front bezel on a flat surface and locate the power-button board.
2. Bring the AlienFX LED board near the front bezel and connect the power-button board cable to the power-button board.
3. Align the screw hole of the AlienFX LED board to the screw hole on the front bezel.
4. Replace the four screws (M3x8) that secure the AlienFX LED board to the front bezel.
Next steps
1. Install the
front bezel.
2. Install the right-side cover.
3. Install the
top cover.
4. Install the left-side cover.
5. Follow the procedure in After working inside your computer.
Power-button board
Removing the power-button board
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
3. Remove the top cover.
4. Remove the right-side cover.
5. Remove the
front bezel.
6. Remove the front AlienFX LED board.
About this task
The following images indicate the location of the power-button board and provide a visual representation of the removal procedure.
