Processor liquid-cooling assembly
Removing the processor liquid-cooling assembly
Prerequisites
1. Follow the procedure in
Before working inside your computer.
WARNING: Despite having a plastic shield, the processor liquid-cooling assembly may be very hot during normal
operation. Ensure that it had sufficient time to cool before you touch it.
CAUTION: For maximum cooling of the processor, do not touch the heat transfer areas on the heat sink. The oils in your
skin can reduce the heat transfer capability of the thermal grease.
2. Remove the left-side cover.
About this task
The following images indicate the location of the processor liquid-cooling assembly and provide a visual representation of the
removal procedure.
56
