3. Align the screw holes on the processor cooler with the screw holes on the system board.
4. Tighten the four captive screws that secure the processor cooler to the system board.
5. Connect the processor-cooling assembly cables to the system board.
Next steps
1. Install the
left-side cover.
2. Follow the procedure in After working inside your computer.
Processor
Removing the processor
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the
left-side cover.
3. Remove the processor liquid-cooling assembly or processor fan and heat-sink assembly, as applicable.
About this task
The following images indicate the location of the processor and provide a visual representation of the removal procedure.
59
