Alkeria NECTA Series - Page 24

2. Introducing NECTA Line Scan Cameras 23
Specication NECTA N4K2-7 NECTA N4K2-7C
Sensor model AMS DR4X2K7 AMS DR4X2K7-RGB
Sensor type Mono Color
Sensor resolution 2(H) x 4096(W)
Sensor technology CMOS, ll factor 100%
Pixel size 7 µm × 7 µm
Max. line rate (ADC Res. 12 bit) 47 281 lps (all video modes) 23 641 lps (all video modes)
Max. line rate (ADC Res. 9 bit) 95 238 lps (MONO8)
47 733 lps (MONO16)
47 619 lps (MONO16, YUV422)
31 746 lps (RGB24)
A/D conversion 9 to 12 bits
Synchronization External trigger, software trigger
Controls Gain, shutter, frame rate, brightness, contrast, LUT, gamma, trigger
Shutter control 2 µs ÷ 100 ms (100 ns steps)
Binning factor 2x horizontal, 2x vertical None
Readout Normal, ROI, binning, frame combiner, subsampling
Power supply 2.5 W max, powered by USB 3.2 Gen 1x1
Inputs/outputs 2 in, 2 out, 1 I/O (RS-422, RS-644, LV-CMOS, LV-TTL)
Lens adapter C-mount, F-mount, M42
Interface USB 3.2 Gen 1x1
Pixel formats RAW8, RAW16, MONO8,
MONO16
RAW16, MONO16, YUV422,
RGB24
Weight 129 g (with C-mount adapter)
Size (without adapters) 56 mm x 56 mm x 26.7 mm
Size (with C-mount) 56 mm x 56 mm x 38.3 mm
Size (with F-mount) 56 mm x 56 mm x 67.3 mm
Conformity CE, RoHS, FCC, IC
Operating temperature 0 ÷ 50 °C (referred to housing)
Software MaestroUSB3
Link www.alkeria.com/products/NECTA-series
Warranty 24 months
Table 2.6: NECTA N4K2-7 / N4K2-7C Specications
