54 Rockwell Automation Publication 440R-UM012E-EN-P - November 2018
Appendix A Specifications
Input IN1
Table 11 - Inputs IN1
Proximity Sensor Signals
Table 12 - Proximity Sensor Signals
Attribute 440R-GL2S2P
Input signals S12, S22
ON voltage, max 26.4V
ON voltage, min 11V
OFF voltage, max 5V
OFF current, max 2 mA
ON current at 24V DC, max 11.0 mA
ON current at 26.4V DC, max 11.1 mA
Galvanic isolation: I/O from logic No
Overvoltage protection Yes
Test out pulse duration ≤850 µs
Test out pulse period 17 ms
Off pulse accepted for OSSD setting
without declaring the input as OFF
Min = 0 µs
Max = 850 µs
Reverse voltage protection Yes
Input capacitance 10 nF
Attribute 440R-GL2S2P
Input signals P12, P22
ON voltage, max 26.4V
ON voltage, min 6V
OFF voltage, max 5V
OFF current, max 2 mA
ON current at 24V DC, max 6.5 mA
Hole pulse time (low pulse), min 40 µs
Pulse Resolution, max 4 kHz
Galvanic isolation: I/O from logic No
Input capacitance 1 nF
Overvoltage protection Yes
