Allen-Bradley 440R-GL2S2P - Lock Unlock Request; Lock Unlock Signals

Rockwell Automation Publication 440R-UM012E-EN-P - November 2018 55
Specifications Appendix A
Lock Unlock Request
Table 13 - Lock Unlock Request
Lock Unlock Signals
Table 14 - Lock Unlock Signals
Attribute 440R-GL2S2P
Input signals S44, S54
ON voltage, max 26.4V
ON voltage, min 11V
OFF voltage, max 5V
OFF current, max 2 mA
ON current at 24V DC, max 11.0 mA
ON current at 26.4V DC, max 11.1 mA
Galvanic isolation: I/O from logic No
Overvoltage protection Yes
Input capacitance 10 nF
Duration 0.5…3.0 s
Attribute 440R-GL2S2P
Output signals 51 & L62
Continuous output current, max 0.300 A
High side voltage, max 26.4V
High side voltage, min 15V
Low side voltage, max 3V
Surge output current, max 3 A
Surge output current duration, max 10 µs
Load capacitance, max 1 µF
OFF state leakage current, max < 0.1 mA
Short-circuit detection Yes
Short-circuit protection Yes
