Rockwell Automation Publication 440R-UM012E-EN-P - November 2018 57
Specifications Appendix A
Single Wire Safety Output
Signal
Table 17 - Single Wire Safety Output Signal
Safety/Pulse Test Outputs
Table 18 - Safety/Pulse Test Outputs
Attribute 440R-GL2S2P
Output signals L11
Continuous output current, max 50 mA
ON state voltage drop (P/S to +), max 0.2V
Surge output current, max 700 mA
Surge output current duration, max 5 ms
Load capacitance, max 1 µF
OFF state leakage current, max < 0.1 mA
Short-circuit detection No
Short-circuit protection Yes
Galvanic isolation: I/O from logic No
Fanout (# connections to L11, max) 10
Cable length between L11 and L12 30 m (98.4 ft)
Attribute 440R-GL2S2P
Output signals X14, X24
Continuous output current, max 0.5 A
Surge output current, max 1.5 A
Surge output current duration, max 5 ms
Residual voltage (drop from P/S), max 0.2V
Load capacitance, max 1 µF
OFF state leakage current, max < 0.1 mA
Short-circuit protection Yes
Reverse voltage protection Yes (with external fuse required)
Aggregate current of outputs per
module, max
1.8 A
Galvanic isolation: I/O from logic No
Pulse test duration ≤ 850 µs
Pulse test period ≤13000 ms (<15 s)
