Appendix C Leakage Current Specifications
Table 68 - Leakage Current Specifications
Mains Input - Nominal Line
Typical Leakage (Calculated)
Mains Input - High Line (Nominal +10%)
Fault Leakage (Calculated)
Single-phase Three-phase Single-phase Three-phase
Center Ground WYE
Corner Ground
Delta
Center Ground WYE
Corner Ground
Delta
Catalog No. Drive Description
AC Input
Voltage
(rms)
Continuous
Output Current
(rms)
Number of
Phases
No External Filter
With External
Filter
No External
Filter
No External Filter
With External
Filter
No External
Filter
2097-V31PR0-LM
120/240V,
single-phase,
doubler
120V
2 A
1
7 mA pk ———7 mA pk ———
240V 7 mA pk ———8 mA pk ———
2097-V31PR2-LM
120V
4 A
6 mA pk ———7 mA pk ———
240V
7 mA pk ———8 mA pk ———
2097-V32PR0-LM
208/240V,
single-phase, with
integrated filter
240V
2 A 27 mA pk ———29 mA pk ———
2097-V32PR2-LM 4 A 26 mA pk ———28 mA pk ——— 2097-V32PR4-LM 8 A 26
mA pk ———29 mA pk ———
2097-V33PR1-LM
208/240V,
single/three-phase
240V
2 A
1 18 mA pk ———20 mA pk ———
3
— 2 mA pk ———2 mA pk ——
——
1 mA pk ———1 mA pk —
———29 mA pk ———31 mA pk
2097-V33PR3-LM 4 A
1
18 mA pk ———19 mA pk ———
3
—
2 mA pk ———3 mA pk ——
——1 mA pk ———1 mA pk — ———28 mA pk ———31 mA pk
2097-V33PR5-LM 8 A
1
17 mA pk ———19 mA pk ———
3
— 2 mA pk ———3 mA pk ——
——2 mA pk ———2 mA pk — ———
28 mA pk ———30 mA pk
2097-V33PR6-LM 12 A
1 19 mA pk ———20 mA pk ———
3
— 3 mA pk ———3 mA pk ——
——
12 mA pk ———13 mA pk —
