Allen-Bradley MicroLogix 1100

To Next Page

To Previous Page

Publication 1763-RM001C-EN-P - October 2009

Using High-Speed Outputs 131

Stage 0 1 2 3 4 5 6 7 8 9 10 11 12

Rung State

Sub-Elements: Relative Timing

Normal Operation/NO

Accelerate Status/AS

Run Status/RS

Decelerate Status/DS

Enable/EN

Done/DN

Idle/ID

Jog Pulse/JP

Jog Continuous/JC

Start of PTO
