Publication 1763-RM001C-EN-P - October 2009
498 Fault Messages and Error Codes
xx8C
(1)(2)
EXPANSION I/O
OBJECT TYPE
MISMATCH
An expansion I/O object (i.e. cable,
power supply, or module) in the user
program I/O configuration is not the
same object type as is physically
present.
Non-User Correct the user program I/O configuration
so that the object types match the actual
configuration, and
Re-compile, reload the program and enter
the Run mode. Or
Correct the actual configuration to match
the user program I/O configuration.
Cycle power.
0x1F39 INVALID STRING
LENGTH
The first word of string data contains
a negative, zero, or value greater
than 82.
Recoverable Check the first word of the string data
element for invalid values and correct the
data.
(1) xx indicates module number. If xx = 0, problem cannot be traced to a specific module.
(2) The xx in this error code means that the error occurs at the location of the last properly configured Expansion I/O module +1. You should use this information in conjunction
with the specific error code to determine the source of the problem.
Error
Code
(Hex)
Advisory Message Description Fault
Classification
Recommended Action
